FireEye CM Series (Giải pháp quản lý tập trung)

Mã sản phẩm #

Thông tin mô tả

Tính năngGiải pháp CM series cho phép quản lý tập trung nhiều thiết bị FireEye trên 1 giao diện duy nhất. – Thiết lập và tinh chỉnh cấu hình thiết bị. – Hiển thị toàn bộ thông tin về tình trạng thiết bị, các cảnh báo, báo cáo. – Cho phép chia sẻ dữ liệu giữa các thiết bị được quản lý theo thời gian thực.
Thông số kỹ thuật
CM 4400 CM 7400 CM 9400
Network Interface Ports 2x 10/100/1000BASE-T Ports 2x 10/100/1000BASE-T Ports 2x 10/100/1000BASE-T Ports
Management Ports (rear panel) 2x 10/100/1000BASE-T Ports 2x 10/100/1000BASE-T Ports 2x 10/100/1000BASE-T Ports
IPMI Port (rear panel) Included Included Included
Front Panel LCD & Keypad Included Included Included
PS/2 Keyboard and Mouse, DB15 VGA Ports (rear panel) Included Included Included
USB Ports (rear panel) 2x Type A USB Ports 2x Type A USB Ports 2x Type A USB Ports
Serial Port (rear panel) 115,200 bps, No Parity, 8 Bits, 1 Stop Bit 115,200 bps, No Parity, 8 Bits, 1 Stop Bit 115,200 bps, No Parity, 8 Bits, 1 Stop Bit
Storage Capacity 4x 600 GB HDD, RAID 10, 2.5 inch, FRU 4x 600 GB HDD, RAID 10, 2.5 inch, FRU 4x 800 GB SSD, RAID 10, 2.5 inch, FRU
Enclosure 1RU, Fits 19 inch Rack 2RU, Fits 19 inch Rack 2RU, Fits 19 inch Rack
Chassis Dimensions (WxDxH) 17.2” x 27.8” x 1.70”(437 x 706 x 43.2 mm) 17.2” x 28.0” x 3.41” (437 x 711 x 86.6 mm) 17.2” x 28.0” x 3.41” (437 x 711 x 86.6 mm)
AC Power Supply Redundant (1+1) 750 watt, 100 – 240 VAC, 9 – 4.5A, 50-60 Hz, IEC60320-C14 inlet, FRU Redundant (1+1) 750 watt, 100 – 240 VAC, 9 – 4.5A, 50-60 Hz, IEC60320-C14 inlet, FRU” Redundant (1+1) 750 watt, 100 – 240 VAC, 9 – 4.5A, 50-60 Hz, IEC60320-C14 inlet, FRU
DC Power Supply Not Available Not Available Not Available
Power Consumption Maximum (watts) 313 watts 351 watts 565 watts
Thermal Dissipation Maximum (BTU/h) 1068 BTU/h 1198 BTU/h 1928 BTU/h
MTBF (h) 35,200 h 60,700 h 60,700 h
Appliance Alone / As Shipped Weight lb. (kg) As Shipped Weight lb. (kg) 32lb.(15kg)/ 47 lb. (21 kg) 42lb.(19kg)/ 57 lb. (26 kg) 42 lb. (19 kg) / 58 lb. (26 kg)
Safety Certifications IEC 60950, EN 60950, CSA 60950-00, CE Marking IEC 60950, EN 60950, CSA 60950-00, CE Marking IEC 60950, EN 60950, CSA 60950-00, CE Marking
EMC/EMI Certifications FCC (Part 15 Class-A), CE (Class-A), CNS, AS/NZS, VCCI(Class A) FCC (Part 15 Class-A), CE (Class-A), CNS, AS/NZS, VCCI(Class A) FCC (Part 15 Class-A), CE (Class-A), CNS, AS/NZS, VCCI(Class A)
Regulatory Compliance RoHS, REACH, WEEE RoHS, REACH, WEEE RoHS, REACH, WEEE
Operating Temperature 10°C to 35°C 10° C to 35° C 10° C to 35° C
Operating Relative Humidity 10% to 85% (non-condensing) 10% to 85% (non-condensing) 10% to 85% (non-condensing)
Operating Altitude 5,000 ft. 5,000 ft. 5,000 ft.

Yêu cầu khi sử dụng thiết bị ảo

MODEL CPU CORES RAM VIRTUAL NICS HARD DISK SPACE
CM2500V 4 32 GB 4 (total): 1 (management) 1-3 (for future use) 512 GB
CM7500V 16 128 GB 4 (total): 1 (management) 1-3 (for future use) 1200 GB

Chi tiết Spec Sheet, vui lòng tham khảo & download Tại đây
